Table of contents
1 Introduction ........................................................
2 Proper use..........................................................
3 Product description (Fig. 1-8).............................
4 Scope of delivery (Fig. 1, 2) ...............................
5 Unpacking ..........................................................
6 Technical data....................................................
7 Safety instructions..............................................
8 Assembly............................................................
9 Before commissioning........................................
10 Operation ...........................................................
11 Electrical connection ..........................................
12 Cleaning and maintenance ................................
13 Storage and transport ........................................
14 Repair and ordering spare parts ........................
15 Disposal and recycling .......................................
16 Troubleshooting .................................................
17 EU-Konformitätserklärung..................................
18 Exploded view ....................................................
Explanation of the symbols on the
product
Symbols are used in this manual to draw your attention to
potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warn-
ings themselves will not rectify a hazard and cannot re-
place proper accident prevention measures.
Attention! Failure to observe the safety signs
and warning information affixed to the prod-
uct and failure to observe the safety and op-
erating manual can result in serious injury or
even death.
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
Before commissioning, read and observe
the operating manual and safety instruc-
tions!
Wear safety goggles.
Wear hearing protection.
If dust builds up, wear respiratory protection!
Attention: hot surface - danger of burning.
18 | GB
18
19
19
19
19
19
20
23
24
24
24
25
26
26
26
27
28
95
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
CAUTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in minor or moderate injury.
ATTENTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in product or property damage.
1 Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
www.scheppach.com
Warning against electrical voltage.
Warning! The product is equipped with an
automated start-up control. Keep third-par-
ties away from the working range of the
product!
Do not expose the product to rain. The prod-
uct may only be stationed, stored and oper-
ated in dry ambient conditions.
Guaranteed sound power level of the prod-
uct.
The product complies with the applicable
European directives.
The product complies with the applicable
Serbian directives.
