• Comply with the stipulated maintenance and safety in-
structions in the operating manual.
• Furthermore, despite all precautions having been met,
some non-obvious residual risks may still remain.
WARNING
In case of extended working periods, the operating per-
sonnel may suffer circulatory disturbances in their
hands (vibration white finger) due to vibrations.
Raynaud's syndrome is a vascular disease that causes
the small blood vessels on the fingers and toes to
cramp in spasms. The affected areas are no longer
supplied with sufficient blood and therefore appear ex-
tremely pale. The frequent use of vibrating products can
cause nerve damage in people whose circulation is im-
paired (e.g. smokers, diabetics).
If you notice unusual adverse effects, stop working im-
mediately and seek medical advice.
6

Unpacking

WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
7

Technical data

Type of motor
Idle speed
Max. engine speed
Rated engine power
Displacement
Dimensions L x W x H
Blowpipe total length
Max. air speed
Max. air flow
Fuel tank volume
2-stroke engine, air-cooled
3500 ± 300 rpm
8000 rpm
1.4 kW
51.7 cm
1380 x 400 x 450 mm
1180 millimeters
295 km/h
3
18 m /min
1 litres
www.scheppach.com
2
CO output
Weight
Subject to technical changes!
Noise and vibration
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
Noise data
Sound pressure level L
Measurement uncertainty K
Sound power level L
Guaranteed sound power level L
Measurement uncertainty K
If necessary, adhere to rest periods and limit the duration
of work to the bare minimum.
Vibration parameters (hand/arm vibration)
Vibration a
hv
Front handle
Rear handle
Measurement uncertainty K
Keep the noise level and vibration to a minimum!
• Only use faultless products.
• Maintain and clean the product at regular intervals.
• Adapt your working methods to the product.
• Do not overload the product.
• Have the product checked if necessary.
• Switch the product off if it is not in use.
• Wear gloves.
Observe the following information to reduce hazards:
• Keep your body and especially your hands warm in
cold weather.
• Take regular breaks and move your hands to promote
circulation.
• Ensure as little vibration as possible of the product via
regular maintenance and stable parts on the product.
8

Assembly

Note:
Place the product on a level, even surface.
Tool required:
• Installation spanner (17)
8.1 Assembling the blowpipe (Fig. 3, 4)
3
1. Attach the hose clamps (12b/12c) to the flexible tube
(12).
2. Slide the flexible tube (12) over the connection on the
motor unit (4) and tighten the hose clamp (12b). Use
an installation spanner (17).
3. Put the handle (2) over the top tube (13) and align the
handle (2) and the guide.
1069 g/kWh
pA
pA
wA
wA
wA
h
7.84 kg
95.2 dB
3.0 dB
110.9 dB
114 dB
3.0 dB
1.79 m/s²
2.3 m/s²
1.5 m/s²
GB | 27
