damage caused by improper use or incorrect
operation.
The device is part of the X 20 V TEAM
series and can be operated with batteries
of the X 20 V TEAM series. Batteries of the
X 20 V TEAM series may only be charged
using chargers of the X 20 V TEAM series.

Scope of delivery/accessories

Unpack the device and check that
everything is present.
Dispose of the packaging material properly.
• Cordless Angle Grinder
• Auxiliary handle
• Cutting disc (pre-assembled)
• Attachment (Guard cover) (pre-as-
sembled)
• Chuck key
• Battery
• Charger
• Storage case
• Translation of the original instructions

Overview

The illustrations for the device
can be found on the front and
back fold-out page.
1 Spindle lock
2 Holder (Auxiliary handle)
3 On/Off switch
4 Handle
5 Battery holder
6 Rotary dial
7 Auxiliary handle
8 Guard cover
9 Cutting disc
10 Direction of rotation arrow
11 Chuck key
12 Attachment (Guard cover)
13 Battery
14 Battery release
15 Button (Charge level indicator)
16 Charge level indicator
17 Charger
18 Charging slot
19 Storage case
GB
Fig. A
20 Hexagon socket screw (3×)
21 Fastening disc
Fig. B
22 Clamping nut
23 Mounting flange
24 Uptake spindle
Fig. D
25 Lock (Attachment)

Description of functions

The very fast rotating attachment tool en-
ables clean grinding, cutting or brushing of
metal.
Special attachment tools are provided for
each of the separate applications.
Please refer to the information from the man-
ufacturer.
Please refer to the descriptions below for in-
formation on how the operating elements
work.

Technical data

Cordless Angle Grinder ..... PWSA 20-Li D4
Rated voltage U ..................................20 V ⎓
Protection type ....................................... IPX0
No-load rotation speed n
........................................2500 – 11500 min
Weight with battery (20 V, 4 Ah) ......... 2.41 kg
Mounting flange ......................... Ø 22.23 mm
Thread .....................................................M14
Thread length of grinding spindle .... ≈ 11 mm
Sound power level (L
WA
Sound pressure level (L
......................................... 84.2 dB; K
Vibration (a )
h
– Handle ....................1.149 m/s²; K=1.5 m/s²
– Auxiliary handle ......1.594 m/s²; K=1.5 m/s²
Battery .................................................. Li-Ion
Temperature .......................................≤ 50 °C
– Charging .......................................4 – 40 °C
– Operation ..................................... 4 – 50 °C
– Storage .......................................15 – 25 °C
PARKSIDE Performance Smart battery
Smart PAPS 204 A1/Smart PAPS 208 A1/
Smart PAPS 2012 A1
– Frequency ƒ ................. 2400 – 2483.5 MHz
– transmitted power ....................... ≤ 20 dBm
IE NI CY
0
−1
) 92.2 dB; K =3 dB
WA
)
pA
=3 dB
pA
5
