Autofocus
* Precautions:
01. When using chuck, roller, or engraving/cutting irregular
objects, like pebbles, soft materials such as office paper, kraft
paper, cashmere cloth, denim, etc, it is recommended to use a
fixed focus block to focus manually;
02. If there is a prompt of exceeding the maximum range, it is
necessary to raise the engraved object to ensure that the laser
module can touch the object within the effective stroke.
03. Keep a distance of at least 5mm between the laser slider and
the base; at the same time, make the laser be in natural contact
with the object, tighten the fixing screws to ensure the smooth
operation of autofocus.
5mm
Wrong
Correct
Instructions:
Operation method 1
1. When the "Autofocus" switch button is turned on
2. Click the "Start" button, the laser module moves to the center of the
screen for automatic focus, and starts engraving after the focus is completed
Note: When the "Autofocus" switch button is turned off, the autofocus
function will not be executed after clicking the "Start" button
Operation method 2
1. When the "Autofocus" switch button is turned on or off
2. Click the "Focus" button, the laser module performs autofocus
at the current position
3. After the focus is completed, click the "Start" button, and the laser
will start the engraving operation
( A ) How to set "Autofocus" function in LightBurn:
01. Find "Window" in the top navigation bar, and enable "Console"
function in the drop-down menu
