ATOMSTACK R3 PRO Bedienungsanleitung

The support block is mainly used for supporting the engraving of large flat objects.
The ball on the support block can be rotated at will. Generally, each support block is
placed on the front and back to coordinate the R3 rotating roller. The R3 rotating roller and
the support block are working When the carving object can slide back and forth, the
support block can be placed at will according to the size of the carving object.
When the R3 rotating roller coordinates with the support block to engrave, the
engraved object may deviate. The laser of the engraving machine has relatively high
energy during the processing, which may cause the fire.
The engraving machine should be supervised during processing to prevent any loss
or damage.
Flat board material
roller
ATOMSTACK
Support block user manual
Support block
Engraving machine
roller
Support block
R3 rotates the roller
