Setting
4
1)
the actual value depends on the available feed-in power
Integrating the If several DATCOM components are networked together in a Solar Net, a terminating plug
Fronius Power must be connected to every free DATCOM component IN or OUT connection.
Control Card into
the Fronius Solar
Net
Operating mode
Master in test mode
4
0
Slave in test mode
4
4
Master in 4-relay mode (factory
4
setting)
1
Master in 2-relay mode
4
or
2
Master without ripple control
signal receiver
Master in 3-relay mode
4
or
3
Master without ripple control
signal receiver
Slave in 4-relay mode
4
5
Slave in 2-relay mode
4
or
6
Slave without ripple control
signal receiver
Slave in 3-relay mode
4
or
7
Slave without ripple control
signal receiver
Master for a control unit ac-
4
8 cording to the Italian standard
CEI 0-21
Slave for a control unit accord-
4
9 ing to the Italian standard CEI
0-21
Reserved for future modes
4
A - F
Currently no valid settings.
NOTE! Follow the operating instructions for the inverter and in 'Fronius DATCOM
Details'.
Whether a ripple control signal re-
ceiver is present or not, up to 10%
1)
of the maximum possible output
power is fed into the grid.
Depending on the setting of the
ripple control signal receiver,
1)
100%, 60%, 30% or 0%
maximum possible output power
is fed into the grid.
Depending on the setting of the
control unit
- inner and outer frquency lim-
its are enabled or disabled,
- the inverter ist forced into
standby operation (no mains
power supply)
of the
