8.3 Spigot SMS 3008 (connection code 37)
DN øc ød
20 16.0 18.0
25 22.6 25.0
40 35.6 38.0
50 48.6 51.0
65 60.3 63.5
80 72.9 76.1
100 97.6 101.6
Dimensions in mm
n = number of bolts
www.gemu-group.com
SW
s t L
1.0 6.1 142.2
1.2 7.4 162.3
1.2 8.3 182.2
1.2 10.2 193.0
1.6 12.5 254.1
1.6 14.0 276.9
2.0 14.5 304.9
LB LS
L
LB LS H1
28.0 58.6 38.0
32.1 65.1 48.0
46.0 68.1 60.0
59.6 66.7 69.0
77.1 88.5 89.0
91.7 92.6 98.0
118.3 93.3 130.0
45 / 64
B
n x ØL Ct B
4 x M6 67.6 125.0
4 x M8 78.4 160.0
4 x M12 100.8 202.0
4 x M14 109.7 202.0
4 x M14 137.2 300.0
4 x M16 146.2 300.0
6 x M16 185.8 350.0
