8 Dimensions
8.2 Spigot DIN EN 10357 (connection code 17)
DN øc ød
10 10.0 13.0
15 16.0 19.0
20 20.0 23.0
25 26.0 29.0
32 32.0 35.0
40 38.0 41.0
50 50.0 53.0
65 66.0 70.0
80 81.0 85.0
100 100.0 104.0
Dimensions in mm
n = number of bolts
GEMÜ B24
SW
L LB LS
120.1 24.3 47.9
140.1 24.3 57.9
140.0 31.2 54.4
152.0 34.0 59.0
165.0 44.0 60.5
190.0 55.0 67.5
203.0 68.9 67.0
254.0 82.0 86.0
280.0 96.0 92.0
308.0 122.0 93.0
LB LS
L
H1 n x ØL
37.0 4 x M6
37.0 4 x M6
40.0 4 x M8
48.0 4 x M8
53.0 4 x M10
63.0 4 x M12
72.0 4 x M14
92.0 4 x M14
102.0 4 x M16
132.0 6 x M20
44 / 64
B
s SW Ct
1.5 19.0 66.6
1.5 19.0 66.6
1.5 19.0 69.5
1.5 22.0 78.6
1.5 22.0 83.6
1.5 27.0 104.0
1.5 27.0 113.0
2.0 32.0 140.0
2.0 32.0 150.0
2.0 38.0 187.3
