Operation

Starting reference run

B
1
2
3
4
22
Lights up continuously
The drive unit recognises the required parameters using the refer-
ence run�
Reference run is required: LED flashes
Close the front manually
Press on front: The reference run starts automatically
Front opens and closes 2x automatically: Under no circumstances
should you try to manually interrupt or stop the process�
NOTE
If the reference run is interrupted, it should be reset
→ see Reset motion E 1� The reference run restarts�
MA-502
Flashes
