Button Layout - blum SERVO-DRIVE Montageanleitung

SERVO-DRIVE for AVENTOS
A
Activating the SERVO-DRIVE switch
B
Starting reference run
Deactivation
E
Reset motion
F
Reset wireless

Button layout

20
Additional features
C
Synchronisation activation
D
Collision avoidance activation
MA-502
1 Drive unit
2 <Reset Motion> button
3
Motion LED
4 <SWITCH> button
5 <SYNC> button
6 <COLL> button
7 <Reset Wireless> button
8 Wireless LED
9 SERVO-DRIVE switch
