Connecting node assembly

NOTE
1
4
➢ Do not damage
3
2
piercing pins�
5
6

Transformer assembly

Transformer unit housing for base fixing
Transformer unit housing for panel fixing
1
2
Transformer unit housing – Assembly on the top panel
