blum SERVO-DRIVE Montageanleitung Seite 37

A1 Blum transformer with LED display
A2 Transformer unit housing for base fixing
A3 Transformer unit housing for panel fixing
A4 Flex
Distribution cable for cutting to size
A5
Connecting node
A6
A7 Cable end protector
A8 Blum distance bumper
B1 Lift mechanism
B2 Telescopic arm or lever arm
Drive unit with LED display
B3
B4 Cover cap
B5 SERVO-DRIVE switch with battery display
C1 Bracket profile vertical
Bracket profile cable (for power supply)
C2
Communication cable
C3
C4 Upper/Back bracket profile attachment
C5 Lower bracket profile attachment
C6 Bracket profile cover cap
C7 Attachment bracket 1 tier
C8 Attachment bracket 2 tier
Bracket profile horizontal
C9
Bracket profile attachment left/right
C10
Adapter for drive unit
C11
C12 Upper attachment bracket with adapter for drive unit
C13 Drive unit
