If you commission the function module with a configuration other than the default
é
setting, plese refer to the instructions in the column "with individual setting".
Make sure
- that you have correctly set the setpoint range using the DIP switch on the
- and that C0034 is adapted to the setting of the DIP switch.
- Example: Setpoint input (0 ... 5 V) via potentiometer at X3/7, X3/8 and X3/9
é
The controller can operate only if a HIGH level is applied at X3/28 (controller enable
via terminal).
- Please note that the controller inhibit can be set by several sources. The sources
- If the controller does not start despite controller enable via X3/28, check whether
Step
1. Plug in keypad
2. Connect
mains voltage
3. Trigger digital
inputs
4. Enter setpoint
5. Enable
controller via
terminal
Commissioning
function module
Õ
C0034 = 0, DIP switch 1 = OFF, 2 = OFF, 3 = ON, 4 = OFF, 5 = OFF
act like a series connection of switches.
the controller is inhibited by another source.
with default setting
The controller is ready after approx. 1 second.
Controller inhibit is active
E4 E3
CW
LOW
rotation
LOW LOW LOW LOW LOW LOW
CCW
HIGH
rotation
Set a voltage 0 ... + 10 V at X3/8
X3/28 = HIGH (+ 12 ... + 30 V)
with individual
setting
é
Adapt digital
E2 E1
inputs to your
application application
under C0007 or
C0410
é
Trigger digital
input such that input such that
the drive can
start via
terminals after
controller enable
é
Depending on
the DIP switch at
the module:
- Apply current
or voltage at
X3/8
- Check C0034
- 8 -
Reaction of the
drive
dc
Green LED is
flashing
Keypad:
c
Green LED is
illuminated
is no longer
illuminated
The drive is running
now.
EDK82ZAFS 1.0
