X3 Signal Function (bold =
type default setting)
8 Analog Actual value or
input setpoint input
(Change range
using DIP switches
and C0034!)
62 Analog Output frequency
output
28 Controller inhibit
(CINH)
E1 E1 Activation of fixed Activation of fixed
1) 1)
f frequencies (JOG)
JOG1 JOG1 = 20 Hz
E2 E2
JOG2 = 30 Hz JOG2 = 30 Hz
Digital Digital
JOG3 = 40 Hz
inp ts inputs
E3 DC injection
braking (DCB)
E4 E4 Reversal Reversal
CW/CCW rotation
A1 Digital Ready
output
9 - Internal, stabilized
DC voltage source
for setpoint
potentiometer
20 - Internal DC voltage
source to trigger
digital inputs and
outputs
59 - DC supply for A1
7 - GND1, reference
potential for analog
signals
39 - GND2, reference
potential for digital
signals
1)
optionally frequency input 0 ... 10 kHz, configuration via C0425

Terminal description

Level
0 ... + 5 V
0 ... + 10 V
-10 V ... + 10 V
0 ... + 20 mA
+ 4 ... + 20 mA
+ 4 ... + 20 mA
(open circuit monitoring)
0 ... + 10V
1 = START
i (JOG)
JOG1
20 Hz
JOG2
JOG3
1 = DCB active
CW
CCW
0/+ 20 V for DC intern
0/+ 24 V for DC extern
+ 5.2 V (reference: X3/7)
+ 20 V (reference: X3/7)
+ 20 V (internal, jumper to
X3/20)
+ 24 V (external)
-
-
E1 E2
1 0
0 1
1 1
E4
0
1
- 6 -
Technical data
Resolution: 10 Bit
Linearity error: ±0.5 %
Temperature error:
0.3 % (0 ... + 60°C)
é
Input resistance
é Voltage signal: > 50 k
Current signal: 250
Resolution: 10 Bit
Linearity error: ±0.5 %
Temperature error:
0.3 % (0 ... + 60°C)
Load capacity: max. 2 mA
Input resistance: 3.3 kΩ Input resistance: 3.3 kΩ
1 1 = HIGH = HIGH
(+ 12 ... + 30 V) (+ 12 ... + 30 V)
0 = LOW
(0 ... + 3 V)
(PLC level, HTL) (PLC level, HTL)
Load capacity:
10 mA
50 mA
Load capacity: max. 10 mA
Max. load capacity:
É
I = 40 mA
mains isolated from GND2
mains isolated from GND1
EDK82ZAFS 1.0
