These instructions
é
include the most important technical data, describe the installation, handling and commissioning of
é the function module.
is valid only
- for function modules labelled E82ZAFS
- for function modules labelled E82ZAFS001 (coated)
- together with the operating instructions of the corresponding controller.
Description
The E82ZAFS function module trigger Lenze controllers with analog and digital control signals.
Scope of application
The keypad can be used with controllers as from the nameplate labelling:
é
8200 frequency inverters
- E82xVxxxxxBxxxXX0x0x (8200 vector / 8200 motec)
Accesssories
A screw driver is attached using which the terminals of the function modules can be tightened or loosened.
The electrical connections and interfaces are live at least three minutes
after disconnecting the controller from the supply voltage.
Function module
Standard-I/O
(
