Signal to X3/8 Signal to X3/8
0 ... 5 V
0 ... 10 V (default setting)
0 ... 20 mA
4 ... 20 mA
4 ... 20 mA open circuit monitoring
-10 V ... + 10 V
Always set DIP switches and C0034 to the same range, otherwise the
controller will misinterprete the analog input signal at X3/8.
If a setpoint potentiometer is supplied internally via X3/9, the DIP switch
must be set to the voltage range 0 ... 5 V. Otherwise it is not possible to use
the complete speed range.

Switch setting

Switch setting
1 2
OFF OFF
OFF OFF
OFF OFF
OFF OFF
OFF OFF
ON ON
- 4 -
3 4
ON OFF OFF
ON OFF
ON ON OFF
ON ON OFF
ON ON OFF
OFF OFF OFF
C0034 C0034
5
0
ON 0
0
1
3
2
