TECHNICAL DETAILS

38
Flat surface m 2 37.92
Projected surface m 2 32.47
Span m 13.63
Projected span m 10.85
Aspect ratio m 4.90
Projected aspect ratio m 3.63
Max chord m 3.46
Min chord m 0,77
Number of cells 46
Take off weight
(pilot, wing, equipment) kg 115/195
Weight of the glider kg 8.7
Maxi length of the lines with the risers cm 838
Minimum speed km/h 24
Max speed without trimmers km/h 39
Max speed with trimmers km/h 45
Min. sink rate m/s 1.1
Glide 7.9
Surface, span and aspect ratio are calculated from the computer
and are measured on the axis of the profile.
41 THE MATERIALS
41.15 The BI BETA 3, like all ADVANCE products, is the result of the
35.22 latest developments and experience in the sport. All the materials
14.20 used for the paraglider have been carefully selected in order to
11.30 give our products an excellent longevity. The materials are syste-
4.90 matically tested and all canopies undergo quality control testing.
3.63 The lifetime of a wing may vary according to the care given to the
3.60 utilisation and maintenance.
0.80
46 Upper surface, leading edge and cell ribs :
Nylon Porcher Marine Waterrepellent New Skytex 6.6 / 44 gr/m
135/225
9.4 Lower surface :
873 Nylon Porcher Marine Waterrepellent New Skytex 6.6 / 40 gr/m
24
39 Reinforcement of the leading edge and trailing edge :
45 Polyester / Mylar 30 mm
1.1
7.9 Reinforcement of the leading edge lower surface :
Polyamid 16 mm
Suspension lines :
Liros Dyneema + Technora, sheathed Polyester
DFL 115 / 1,2 mm (1st level and brake)
PPSL 200 / 1,45 mm (2nd level)
TSL 280 / 1,8 mm (3rd level)
Risers :
Polyester 28 mm - 1500 kg
Quick links :
2 Inox, 4 mm - 1000 kg
2

PRE-DELIVERY INSPECTION

Before supplying your canopy your sales agent should make a
general test flight and set the brakes.
