CCR3 Controller
ENGLISH
10. REAL TIME CLOCK SETTINGS (code 576)
8 | © Danfoss | 2016.10
No LCD Display FUNCTION DESCRIPTION
30 AlertRel Alarm output (Triac)
... ... StillOn – continuos alarm signal: T2 – 24 VAC
Pulse – pulse alarm signal 24 VAC every second
Factory setting: Pulse
31 Archiver Information about data archiving:
... Never – the feature is switched off,
1 File – data is stored in one file on the SD card,
2 Files – data is stored alternatively in two files to improve write reliability. This function decreases term of
date storage (twice).
Factory setting: 1 File
32 ArchFreq Data archiving interval. The time can be set to any value between 10 seconds and 4 hours. The data from
... each day saved in different files (with data name).
Factory setting: 1 min
33 DateForm Form of date display:
YY-MM-DD – year, month, day
YY-DD-MM – year, day, month
DD-MM-YY – day, month, year
MM-DD- YY – month, day, year
Factory setting: YY-MM-DD
34 Reset Reset to factory settings
....... Yes - return to factory settings
No – keep adjust settings
Note: To complete reset procedure turn CCR3 off and back on.
35 Ecs? Exit windows from Install Menu. Enter "+" to closed setting or basic menu will close automatically after 4 minutes
+ YES
From ACCESS CODE menu enter code: 576
(procedure in chapter 7). The Real Time menu is
displayed as detailed in the table below.
The arrow keys "▲/▼"move the menu windows,
the "+/-"keys change the values in the window
selected by the arrows.
No LCD Display INSTALL MENU - FUNCTION DESCRIPTION
36 Real Time Information about menu: real Time
Menu
37 RealTime Sets the real time clock "hour"
12:00:00
38 RealTime Sets the real time clock "minute"
12:00:00
39 RealTime Sets the real time clock "second"
12:00:00
40 Year Sets the year for the current date
41 Month Sets the month for the current date
42 Day Sets the day for the current date
43 Ecs? Exit windows from Install Menu. Enter "+" to closed setting or basic menu will close automatically after 4 minutes
+ YES
To exit the setting menu, press the up arrow key after
changing the last setting. The setting menu is closed
automatically after 4 minutes of inactivity.
VI.D3.A3.02
