CCR3 Controller
ENGLISH
13. CCR3 ModBus PROTOCOL
Data type: Coil [bool]
Data type: Register
[integer]
Baud rate:
10 | © Danfoss | 2016.10
Coil No.
MB_CoilOut [2 ... 9]
MB_CoilOut [10 ... 17]
Register No.
MB_RegisterOut [0 ... 8]
MB_RegisterOut [9 ... 16]
MB_RegisterOut [17 ... 24]
MB_RegisterOut [25 ... 32]
MB_RegisterOut [36+0 ... 7] - control signal (opening) in % for valve in risers: 1 ... 8
MB_RegisterOut [44+0 ... 7] - control signal (opening) % for valve in riser: 9 ... 16
data bits stop bits
9.600 8+1
19.200 8+1
38.400 8+1
Description
- open valves (0 ... 7)
- risers with open valves (riser: 8 ... 15)
Description
- temperature sensors S0 ... S8 (8000 <=> 80 °C)
- temperature sensors S9 ... S16 (8000 <=> 80 °C)
- temperature setting for risers 1 ... 8
- temperature setting for risers 9 ... 16
parity
N
N
N
VI.D3.A3.02
