INSTRUCTION MANUAL
WARNING: READ THE INSTRUCTION MANUAL CAREFULLY BEFORE
USING THE STARTER!
1. GENERAL SAFETY USER INSTRUCTIONS FOR THIS STARTER
In order to reduce the risk of personal injury and damage to
equipment, it is highly recommended to comply with all essential
safety measures and precautions when using the starter.
- Inexperience and untrained people should be properly instructed
before using the appliance.
- This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
- Children shall not play with the appliance.
- Cleaning and user maintenance shall not be made by children
without supervision.
- Protect the eyes. Always wear protective goggles when using
acid lead accumulators.
- Avoid contact with battery acid. If an operator should be
sprayed or come into contact with the acid, rinse the relative
parts immediately under clean running water.
Continue to rinse the area until the physician arrives.
- It is important to connect the cables with the poles in the right
direction:
First connect the red clamp to the positive terminal on the
vehicle battery (+ symbol).
Connect the black clamp to the vehicle chassis or the negative clamp on
the battery, at a distance from the fuel pipe.
- Use the starter in well ventilated areas. Do not attempt to use the
starter when there is gas or inflammable liquids in the vicinity.
- Do not allow the black and red clamps to come into contact.
- USE IN EMERGENCY SITUATIONS ONLY: do not use the starter instead of
the vehicle battery. Use it during start-up operations only.
- Do not work alone. If there is an accident, the assistant can be of aid to
the operator.
- Prevent electrical shocks. Be very cautious when applying the
clamps to non-insulated conductors or bus bars. Avoid all
body contact with surfaces of tubes, radiators, and metal
power substations whilst reading the vehicle battery voltage.
- Keep the work area clean at all times. Untidy cumbersome areas can lead
to injuries.
- Protect the starter appropriately from all possible damage. It must only
be used as indicated in this Instruction Manual.
- Ensure compliance with the indications in the work area. Do not use in
humid or wet facilities. Never leave it out in the rain. Always work in well
lit areas.
Always wear suitable clothing. Never wear baggy clothing
-
or jewellery that can get caught up in moving parts.
During all operations, the use of electrically insulated
protection clothing and non-slip boots must be worn at all times.
Persons with long hair must tie it back and wear a hair net.
- Only experts are allowed to do repair work on the starter as it involves
significant risk levels for inexperienced workers.
- Replacing parts and accessories. When performing maintenance
operations, replace with identical and original spare parts only. Use of
non-original spare parts invalidates all warranties.
- Make sure that the device is always positioned in a stable and well
supported manner.
Never climb over cables or electrical structures.
- Careful attention must be paid during maintaining work on the starter.
Check the condition of cables on a regular basis and if any damage
is detected, have the same repaired by an authorised and qualified
technician.
- Check there are no damaged parts. Before using this starter, carefully
check that all seemingly damaged parts and assess whether or not they
can operate correctly. Check that the cables are securely fastened to the
starter. Remember that only authorised and qualified technicians are

(EN)

allowed to repair or replace damaged parts.
1.1 SPECIAL WARNINGS AND SAFETY PRECAUTIONS ON THE USE OF
THE LITHIUM BATTERIES INSIDE THE STARTER
Failure to observe the following rules can cause breakage, overheating,
bulging, fire outbreak or explosion of the battery inside the starter:
- Never open the starter casing under any circumstances.
- Do not charge the battery in direct sunlight, near flames or in similar
conditions.
- Do not use the starter or position it in the vicinity of heaters, near flames
or in other hot areas.
- Only use the charger supplied with the device to charge the starter or
optional charger systems sold separately.
- Do not throw the starter into a fire or heat it up.
- Do not invert the positive "+" and negative "-" connection polarities.
- Do not short-circuit the starter terminals.
- Do not perforate the starter casing with drill bits, do not hit it with a
hammer or stand on it.
- Do not position the starter inside stoves, microwave ovens etc.
- Do not throw the starter or cause high impacts.
- Do not modify or tamper with the starter casing.
- Refrain from using the starter if it emits strange smells, heats up or
deforms during use, charging or storage.
- Models with 12V voltage only:
Use is forbidden on vehicles with voltage other than 12V.
Use is forbidden for applications other than specified.
Keep this manual.
The manual should be read, paying attention to all the warnings and safety
precautions to be taken when using and maintaining the device, the list of
components and all technical specifications.
Please keep this manual in a secure and dry place for future reference.

2. INTRODUCTION AND GENERAL DESCRIPTION

Intended use
Portable multifunction battery starter. Ideal for anyone who needs an
emergency starter. Its applications include motorcycles, cars, boats and
more. Fully compatible with any 12-volt and 24-volt starting system
(12V/24V model only).
The starter uses LITHIUM BATTERIES, which makes the device extremely
easy to handle and compact. The multifunction starter is also equipped
with a powerful LED light and a USB output port for powering and/or
charging electronic devices.
3. DESCRIPTION OF THE STARTER
3.1 STARTER ASSEMBLY AND MAIN COMPONENTS (Fig. A)
1. Multifunction starter with starter cables and clamps.
2. Load cable with USB type A and C plugs.
3. LED lighting light.
4. USB socket input for charging the starter with the supplied USB cable.
5. Control panel.
6. Side supports for hooking the pliers in the rest position.
7. USB socket for power supply and/or charging of electronic devices
(Power Bank).
8. Connector for selecting 12V or 24V (12V/24V model only).
ATTENTION: In the 12V/24V model, select the voltage
compatible with the vehicle battery.
3.2 CONTROL AND REGULATION DEVICES
3.2.1 Control panel (Fig. B)
1.
Indicates that the start function has been activated.
2.
Indicates that the override function has been activated.
3.
Indicates that a pause is in progress, usually marked by a countdown
timer on the display.
4.
Signals the user to recharge the starter Li battery as soon as possible.
5.
Signals a general alarm combined with other symbols and/or alarm
