5. LOADING THE INTERNAL BATTERY
Important! To obtain maximum battery performance, charge
before use, after each use and in any case every 3 months.
The charge status of the starter Li battery is indicated on the display
as a percentage value and by the horizontal bars of the icon
lighting up.
When the icon appears on the display, the user is advised to
recharge the starter's Li battery as soon as possible.
5.1 CHARGING WITH USB POWER SUPPLY
ATTENTION! Only use a USB power supply that meets the
required specifications (see product data plate).
- Insert the appropriate connector into the USB charging socket (Fig. A-4).
- During the charging process, the horizontal bars of the icon
progressively and dynamically, the charging icon
charge percentage
- The starter is equipped with a control device that prevents the battery
from overcharging.
- When charging is complete, the icon
and the charge percentage
- Remove the power supply connector from the USB charging socket (Fig.
A-4).

6. ALARMS AND WARNINGS

Operating faults, incorrect cable clamp connections, critical battery
conditions, etc. are indicated by symbols and messages on the display.
6.1 ALARMS
- Icon lit and message „A.01" on the display. Starter with DC cables
or reversed polarity; disconnect the output cables.
- Icon lit and message „A.02" on the display. Battery voltage
incompatible with operator selection; select the correct battery- .
With 12V models only, this indicates that the battery voltage is not
compatible and must therefore be disconnected.
- Icons lit and message „A.03" on the display. Lithium cells
of battery 2 excessively discharged; recharge immediately.
- icons lit and message „A.04" on the display. Lithium cells
in battery 1 excessively low; recharge immediately.
If alarms „A.03" or „A.04" persist even after 10 hours from the start of
charging, stop charging and contact the service centre.
7. DISPOSAL OF THE STARTER BATTERY
The starter battery should be recycled. In some countries this is mandatory.
Contact your local solid waste authority for recycling information.
battery, cover the exposed terminals with suitable insulating tape to
prevent short circuits. Do not expose the battery to intense heat or fire
as this could cause an explosion.
SPECIFICATIONS (DRIVE PRO 2012):
Operating ambient temperature:
• -5°C (+23°F) +45°C (+113°F);
Battery type:
• Lithium-polymer battery, sealed, rechargeable;
Battery capacity:
• 12000 mAh;
Start current:
• 12V
800A;
2500A (start peak);
Start cables:
• Cables assembled in the starter;
lights up and the
increases.
turns off, the icon
reaches „100%".
WARNING: Do not dispose of the
battery by burning it. This could cause
an explosion. Before disposing of the
• Copper;
• Section 10.5 mm
• Length 300 mm;
• PVC insulated;
Light:
• White/yellow LED;
Input sockets:
• USB type C charging socket;
Output sockets:
• Type C USB port, QC 18W and PD 6OW;
Features:
• Output protection against polarity reversal, short circuit, overload;
• Protection against excessive battery heating;
• Automatic load cut-off;
• Load level and end of charge indication;
• Continuous, flashing and emergency LED light;
Weight:
• 1.8 kg;
Accessories included (Fig. A):
light up • Charging cable with USB type A and C plugs (Fig. A-2);
SPECIFICATIONS (DRIVE PRO 4024):
Operating ambient temperature:
• -5°C (+23°F) +45°C (+113°F);
Battery type:
• Lithium-polymer battery, sealed, rechargeable;
Battery capacity:
• 24000 mAh;
Start current:
is filled
• 12V
1000A;
4500A (start peak);
• 24V
800A;
2500A (start peak);
Start cables:
• Cables assembled in the starter;
• Copper;
• Section 10.5 mm
• Length 300mm;
• PVC insulated;
Light:
• White/yellow LED;
Input sockets:
• USB type C charging socket;
Output sockets:
• Type C USB port, QC 18W and PD 6OW;
Features:
• Output protection against polarity reversal, short circuit, overload;
• Protection against excessive battery heating;
• Automatic load cut-off;
• Charge level and end of charge indication;
• Continuous, flashing and emergency LED light;
Weight:
• 2.1 kg;
Accessories included (Fig. A):
• Charging cable with USB type A and C plugs (Fig. A-2);
- 5 -
(7 AWG);
2
(7 AWG);
2
