3 • Installation
3.1 • Preparation
3.1.1 • The side guiding channel
4
Narrow side guiding channel fixed
➀
profile
Narrow side guiding channel
➁
removable profile
Inner rail
➂
Base plate
➃
The 2-part narrow side guiding channel can only be placed in mounting situation 7A,
close to the window.
22
Go M 7
1
2
3
4
Deep side guiding channel fixed profile
➀
Deep side guiding channel removable
➁
profile
Inner rail
➂
Base plate
➃
1
2
3
