ATTENTION
Risk of damage!
If incorrectly stored or undrained fuel is used, the carburet-
tor may become clogged or engine operation may be af-
fected.
– Put unused fuel in an airtight vessel and store it in a
dark, cool room.
Place the product on a level, even surface.
Tool required:
• 1 litre measuring beaker (oil / petrol-proof)*
• Funnel*
• Cloth*
* = may not be included in the scope of delivery!
10.1 Filling up with engine oil (Fig. 9)
ATTENTION
The product is delivered without engine oil. Therefore,
ensure that you add oil before starting it up. Use multi-
grade oil (SAE 10W-30 or 10W-40) for this.
Check the oil level regularly before commissioning. An oil
level that is too low can damage the motor.
1. Unscrew the oil dipstick (14).
2. Fill the tank with engine oil using a funnel. Note the max.
filling capacity of 0.4 l. Fill the oil up to the lower edge of
the filling nozzle carefully.
3. Wipe the oil dipstick (14) with a clean, lint-free cloth.
4. Re-insert the oil dipstick (14) and pull it out again.
Check the oil level without screwing the oil dipstick (14)
back in.
5. The oil level must be within the middle mark on the oil
dipstick (14).
6. If the oil level is too low, add the recommended amount
of oil (max. 0.4 l).
7. Then screw the oil dipstick (14) in again.
10.2 Filling up with fuel (Fig. 10)
DANGER
Risk of fire and explosion!
When filling, fuel may ignite and even explode. This can
lead to severe burns or death.
• Switch off the engine and let it cool down.
• Keep heat, flames and sparks away.
• Only fill up with fuel outdoors.
• Wear protective gloves.
• Avoid contact with skin and eyes.
• Start the product at a distance of at least 3 m from the
fuel filling point.
• Watch out for leaks. If fuel is leaking, do not start the
engine.
ATTENTION
The product is delivered without fuel. It is there-
fore essential to fill with fuel before commission-
ing. Use Super E10 petrol for this.
8 | GB
1. Clean the area surrounding the filling area. Impurities in
the fuel tank (8) lead to operational faults.
2. Carefully open the tank cover (7) so that any possible
overpressure can be relieved.
3. Fill the fuel tank (8) with fuel using a funnel (not included
in scope of delivery). Note the max. filling capacity of
0.85 l. Fill the fuel up to the lower edge of the filling noz-
zle carefully.
4. Close the tank cover (7) again. Ensure that the fuel cap
is tightly sealed.
5. Clean the tank cover (7) and the surroundings.
11 Start-up
NOTE
Some noise pollution from this product is un-
avoidable. Postpone noisy work to approved and
designated times. If necessary, adhere to rest pe-
riods and limit the duration of work to the bare
minimum.
For your personal protection and the protection
of nearby persons, wear suitable hearing protec-
tion.
11.1 Setting the cutting height
(Fig. 7+8)
ATTENTION
Adjust the cutting height only when the engine is
switched off and the plug boot has been pulled.
• In dense, tall grass, set the highest cutting level and
mow more slowly. A high cutting height should be se-
lected for the first cut of the season. Adjust the cutting
height so that the product is not overloaded.
• Set the cutting height depending on the actual length of
the lawn.
• Carry out several passes so that a maximum of 4 cm of
lawn is removed at a time.
• The correct cutting height for
– ornamental grass is about 30 mm - 45 mm
– utility turf about 40 mm - 65 mm.
The cutting height is adjusted via the wheels (11). Three dif-
ferent cutting heights can be set.
1. Proceed as described in 9.4 Section 2
11.2 Blade stop device
Before each use, you must check the blade stop device.
Start the engine as described in 12.2.
1. Release the engine brake lever (2). The engine switches
off and the blade (19) is braked.
2. The blade (19) must stop within 7 seconds.
11.3 Preparing the area to be mowed
1. Before mowing, carefully examine the area.
2. Remove stones, sticks, bones, wires, toys and other ob-
jects that may be ejected by the product.
3. Ensure that no other people are present on the surface
to be mowed.
