15 Maintenance
WARNING
Have maintenance and repair tasks that are not
described in this operating manual, carried out by
a specialist workshop. Use only original spare
parts.
There is a risk of accident! Always carry out
maintenance and cleaning work when the engine
is switched off. There is a danger of injury! Let
the Product cool down before all maintenance
and cleaning tasks. Elements of the engine are
hot. There is a danger of injury and burning!
The product can start unexpectedly and cause injuries.
– Switch off the engine before carrying out any cleaning
or maintenance work.
– Disconnect the spark plug connector from the spark
plug.
– Allow the engine to cool down.
• Regular, careful servicing is required to guarantee the
safety level and performance of the product.
• Ensure that all nuts, pins and screws are securely tight-
ened so that the product is in a safe working condition.
• Check the grass collection basket regularly for signs of
wear and loss of functionality.
• For safety reasons, replace worn or damaged parts.
• Check that the front and rear wheels are secured.
• To ensure smooth running of the wheels, we recom-
mend cleaning the wheel axles and wheel hubs at least
once per season.
• Any work not described in this operating manual must
be performed by an authorised specialist workshop on-
ly.
• Place the product on a level, even surface.
Tool required:
• Fuel extraction pump*
• Cloth*
• Open-ended spanner/socket spanner, size 17 mm*
• Open-ended spanner/socket spanner, size 10 mm*
• Oil pump*
• Oil collecting tray, flat (for oil change)*
• Collection bucket*
• Copper wire brush*
• Torque wrench*
• Feeler gauge*
* = may not be included in the scope of delivery!
15.1 Changing the blade (19) (Fig. 13)
WARNING
There is a risk of injury if you work with a dam-
aged blade.
– Wear protective gloves!
– For safety reasons you should only ever have your
blade sharpened and balanced by an authorised spe-
cialist workshop. For optimum results it is recom-
mended that the blade should be inspected once a
year.
– When changing the blade, only use original spare
parts.
1. Empty the fuel tank (8) with a fuel extraction pump be-
fore removing the cutting edge. Never tip the lawnmow-
er to the side or forwards with a full fuel or oil tank!
This will damage the engine and void the warranty.
2. Hold the blade (19) tightly with one hand.
3. Turn the blade screw (20) anticlockwise using a open-
end spanner AF17 from the engine spindle (22). Remove
the washer (21).
4. Re-install the new blade (19) in reverse order. Fasten the
blade screw (20) properly. Make sure that the blade (19)
is correctly positioned and flush against the engine
spindle (22).
5. The tightening torque of the blade screw (20) is 45Nm.
Also replace the blade screw (20) when replacing the
blade (19).
15.1.1 Damaged blades (19)
Should the blade (19) come into contact with an obstruction,
shut down the engine immediately and remove the spark
plug connector (12).
• Check the blade (19) for damage.
• Damaged or bent blades (19) must be replaced.
• Never attempt to bend a bent blade (19) back to straight
again.
• Never mow the lawn with a bent or heavily worn blade
(19) as this will cause vibrations and can lead to further
damage to the lawnmower.
15.2 Checking the oil level (Fig. 9)
WARNING
Health hazard!
Inhalation of fuel / lubricating oil vapours and exhaust gas-
es can cause serious damage to health, unconsciousness
and in extreme cases death.
– Do not breathe fuel / lubricating oil vapours and ex-
haust gases.
– Operate the product outdoors only.
ATTENTION
Product damage!
Using the product without or with too little engine and gear
oil can result in engine damage.
– Fill with fuel and oil before commissioning. The prod-
uct is supplied without engine and gearbox oil.
– Only use SAE 10W-30 or SAE 10W-40 engine oil.
