You can release the spindle lock
(8).
Fitting and removing the
attachment on the guard
cover
CAUTION! Risk of injury
when touching the attachment
tool. Wear protective gloves
when handling the attachment
tool.
Requirements
• Cutting disc mounted
• Battery removed from device
Fitting the attachment (17) (Fig. B)
1. Place the attachment (17) on the
guard cover (5) and turn the at-
tachment (17) until it audibly clicks
into place.
Removing the attachment (17)
(Fig. B)
1. Release one of the two locks (18)
on the attachment (17) by pushing
the lock (18) outwards.
2. Slide the released lock (18) over
the guard cover (5) until the at-
tachment is removed after half a
turn.
Checking the battery
charge level
LEDs
red, orange, green Battery charged
red, orange
red
At the battery
1. Press the button (21) next to the
charge level indicator button (20)
on the battery (22).
Meaning
Battery partially
charged
Battery needs to
be charged
The LEDs of the charge level in-
dicator show how much charge re-
mains in the battery.
2. Charge the battery (22) when only
the red LED on the charge level in-
dicator (20) is illuminated.
At the tool
1. The charge level indicator (11)
lights up during operation. If the
charge level indicator does not
light up, press the Unlock button
(13).
The LEDs of the charge level in-
dicator show how much charge re-
mains in the battery.
2. Charge the battery (22) when only
the red LED on the charge level in-
dicator (11) is illuminated.

Charging the battery

See also the charger instruction
manual.
Notes
• If warm, allow the battery to cool
before charging.
• Do not expose the battery to dir-
ect sunlight for long periods and
do not place it on a radiator (max.
50°C).
Procedure
1. If necessary, remove the battery
(22) from the cordless device.
2. Slide the battery (22) into the char-
ging slot (24) of the charger (23).
3. Plug the charger (23) into an power
outlet.
4. Once charging is complete, dis-
connect the charger (23) from the
mains supply.
5. Pull the battery (22) charging slot
out (24).
