• To comply with the dust emission values for wood-
working and for safe operation, a dust extraction
system with an air speed of at least 20 m/s should
be connected.
• Pass the safety instructions on to all persons who
work on the machine.
• Never use the saw to cut firewood.
• The machine is equipped with a safety switch
against reactivation if the voltage drops.
• Before commissioning, check that the voltage on
the device type plate corresponds to the mains
voltage.
• Only use the cable drum when unrolled.
• Personnel working on the machine must not be
distracted.
• Observe the direction of rotation of the motor and
saw band.
• Safety equipment on the machine must not be dis-
assembled or made unusable.
• Do not cut workpieces that are too small in order
to keep them secure in your hands.
• Never remove loose splinters, chips or jammed
wood pieces from the running saw band.
• The applicable accident prevention regulations
and the other generally accepted safety rules must
be observed.
• Observe the instructions of the employers' liability
insurance association (VBG 7).
• Fit the saw band guard at a height of approx. 3 mm
above the material to be sawn.
• Attention! Secure long workpieces against tipping
at the end of the cutting process. (e.g. roller stand,
etc.)
• The saw band guard (3) must be in the lowest po-
sition close to the table during transport of the de-
vice.
• Protective covers must not be used for transport
or improper operation of the machine.
• Deformed or damaged saw bands may not be
used.
• Replace the worn table insert.
• Never operate the machine when the door protect-
ing the saw band or the guard is open.
• Make sure that the choice of saw band and speed
is suitable for the material to be cut.
• Do not start cleaning the saw band until it has
come to a complete stop.
• Use a push stick when making straight cuts in
small workpieces against the parallel stop.
• Wear gloves when handling the saw band and
rough materials!
• During transport, the saw band guard should be in
the lowest position and close to the table.
• For mitre cuts with an inclined table, the paral-
lel stop should be placed on the lower part of the
table.
• Never use guards for lifting or transport.
28 | GB
• Be sure to use and properly adjust the saw band
guards.
• Keep your hands at a safe distance from the saw
band. Use a push stick for narrow cuts.
• Set the adjustable guards such that they are as
close as possible to the workpiece.
• Store the push stick on the holder provided for it on
the machine so that you can reach it from your nor-
mal working position and always have it to hand.
• In the normal working position, the operator is in
front of the machine.
6. Technical data
AC motor
Power
Idle speed
Saw band length
Saw band width
Max. saw band width
Saw band speed I
Saw band speed II
Cut height
Swing
Table size
Table inclinable
Max. workpiece size
Weight
The workpiece must have a minimum height of 3 mm
and a minimum width of 10 mm.
*Operating mode S1 (continuous operation)
The machine may be operated continuously with the
specified power
* *Operating mode S2 – short-term operation
Operation at a constant load for 20 minutes or less,
followed by a time out of operation and a pause of
sufficient duration to allow the machine to cool to
within 2 K of the ambient temperature.
The noise and vibration levels have been determined
in accordance with EN 61029.
Sound pressure level L
Uncertainty K
Sound power level L
Uncertainty K
www.scheppach.com
220 - 240 V ~, 50 Hz
420W (S1*)
550W (S2 20min**)
1400 min
660 m/min
960 m/min
0-120 mm
300 x 300 mm
580 x 400 x 120 mm
77.4 dB(A)
pA
pA
90.4 dB(A)
WA
WA
-1
1790
6 mm
13 mm
245 mm
0° to 45°
27.5 kg
3 dB
3 dB
