1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new tool brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability
laws, the manufacturer of this device assumes no
liability for damage to the device or caused by the
device arising from:
• Improper handling,
• Non-compliance with the operating manual,
• Repairs carried out by third parties, unauthorised
specialists.
• Installing and replacing non-original spare parts
• Application other than specified
• Failure of the electrical system in the event of the
electrical regulations and VDE provisions 0100,
DIN 13 / VDE0113 not being observed
Please consider:
Read through the complete text in the operating man-
ual before installing and commissioning the device.
The operating manual is intended to help the user to
become familiar with the machine and take advan-
tage of its application possibilities in accordance with
the recommendations.
The operating manual includes important instructions
for safe, proper and economic operation of the de-
vice, for avoiding danger, for minimising repair costs
and downtimes, and for increasing the reliability and
extending the service life of the device.
In addition to the safety instructions in this operating
manual, you must also observe the regulations ap-
plicable to the operation of the device in your country.
Keep the operating manual package with the ma-
chine at all times and store it in a plastic cover to pro-
tect it from dirt and moisture. They must be read and
carefully observed by all operating personnel before
starting the work.
The device may only be used by personnel who have
been trained to use it and who have been instructed
with respect to the associated hazards. The required
minimum age must be observed.
In addition to the safety instructions in this operating
manual and the separate regulations of your coun-
try, the generally recognised technical rules relating
to the operation of such machines must also be ob-
served.
We accept no liability for accidents or damage that
occur due to a failure to observe this manual and the
safety instructions.
2. Device description (Fig. 1)
1
Housing door
2
Door lock
3
Saw band guard
4
Saw band guide
5
Parallel stop
6
Table width extension
7
Saw table
8
Clamping lever
9
Main frame
10 On/off switch
11 Tensioning screw for saw band tension
12 Tensioning screw for belt tension
13 Locking knob for the saw band guard
14 Transverse cutting gauge
15 Machine stand
3. Scope of delivery
• Open the packaging and carefully remove the de-
vice.
• Remove the packaging material, as well as the
packaging and transport safety devices (if pre-
sent).
• Check whether the scope of delivery is complete.
• Check the device and accessory parts for trans-
port damage.
• If possible, keep the packaging until the expiry of
the warranty period.
m Attention!
The device and the packaging are not children's
toys! Do not let children play with plastic bags,
films or small parts! There is a danger of choking
or suffocating!
• Band saw (machine frame)
• Saw table
• Retainer plate
• Rail with scale
• Push stick
• Longitudinal stop
• Allen key (3x)
• Screwdriver
• Open-ended spanner (2x)
• Cross member, top (2x)
• Longitudinal member, top (2x)
• Cross member, bottom (2x)
• Longitudinal member, bottom (2x)
• Foot strut (4x)
• Table width enlargement with guide rail for length-
wise aligning stop
• Fixing material
