TÜV NORD CERT GmbH
Hannover Office
Am TÜV 1
30519 Hannover
Germany
Thermal data:
Permissible range of ambient temperature during operation: -25 °C ... +65 °C
Details of Change:
Proof of conformity to the current standards IEC 60079-0:2017 and IEC 60079-31:2022
Updating drawings
New signal cable (0367399-xxxx) has been added.
Specific Conditions of Use extended.
IECEx TUN 14.0021X issue 01
Special Conditions for Safe Use / Notes for Erection:
1. The max duty cycle specified at an ambient of +25 °C.
LOAD 0-6800 [N]
STROKE
0-600 [mm]
600-1000 [mm]
LOAD 10000 [N]
STROKE
0-1000 [mm]
2.
Ambient temperature area is specified to -25 °C ... +65 °C.
3.
The power supply cable is of special design fulfilling IP 6X ingress protection. The cable
can be delivered in different lengths. Only cables delivered by Linak shall be mounted.
4.
The connection between the actuator and the rest of the machine/device shall be
conductive, and furthermore the application shall be grounded in order to remove any
Electro Static Discharge. This counts for both of the actuator's fixation points (Back
Fixture and Piston Rod Eye).
P17-F-610
Page 2 of 3
Attachment to IECEx TUN 14.0021X issue No.: 02
IECEx TUN 14.0021X issue 02
20% int. - Max. 2 [min.] continuous drive followed by 8 [min.] rest.
15% int. - Max. 3 [min.] continuous drive followed by 17 [min.] rest.
5% int. - Max. 1 [min.] continuous drive followed by 19 [min.] rest.
DUTY CYCLE
DUTY CYCLE
LA36 | 57
Rev. 01 / 06.18
