Set the laser lines such that they cross in the middle of
the drill tip.
Setting the spindle return spring, Fig. 25
The spindle return spring may have to be set, as it's ten-
sion has changed and therefore, the spindle moves back
too quickly or too slowly.
1. Lower the table for more space to work.
2. Work on the left of the drill.
3. Insert a screwdriver into the front groove (L) and
keep this in position.
4. Use an open-ended spanner (AF19) to remove the
outer nut (O).
5. With the screwdriver still in the groove, loosen the
inner nut (N) until the notch (K) releases from the
hub (P). ATTENTION! Springs are tensioned!
6. Turn the spring cap (M) carefully in an anti-clock-
wise direction using the screwdriver until you can
press the groove into the hub (P).
7. Lower the spindle into the lowest position and keep
the spring cap (M) in position. Once the spindle
moves up and down as you require, re-tighten the
inner nut (N).
Inspection and maintenance plan
Regular maintenance intervals
Check safety devices
Check the V-belt and tighten if
necessary
Grease the column and table with
a thin layer of oil
Clean the taper mandrel
Clean the machine of drilling dust
and metal shavings
36 | GB
8. If it is too loose, repeat steps 3-5. If it is too tight,
in reverse order.
9. Use an open-ended spanner to secure the outer
nut (O) against the inner nut (N). NOTE: Do not
over-turn and do not limit the range of movement
of the spindle!
Service information
With this product, it is necessary to note that the follow-
ing parts are subject to natural or usage-related wear,
or that the following parts are required as consumables.
Wearing parts*: Carbon brushes, V-belts, drill bits
* may not be included in the scope of delivery!
Spare parts and accessories can be obtained from our
Service Centre. To do this, scan the QR code on the
front page.
