Residual risks
The machine has been built according to the state-
of-the-art and the recognised technical safety re-
quirements. However, individual residual risks can
arise during operation.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• Furthermore, despite all precautions having been met,
some non-obvious residual risks may still remain.
• Residual risks can be minimised if the "safety instruc-
tions" and the "Proper use" are observed along with
the whole of the operating instructions.
• Do not load the machine unnecessarily: too much
pressure when drilling quickly damages the drill. This
results in reduced output of the machine in the pro-
cessing and in cut precision.
• Avoid accidental starting of the machine: the oper-
ating button may not be pressed when inserting the
plug in an outlet.
• Use the tool that is recommended in this manual. This
is how to ensure that your drill provides optimum per-
formance.
• Keep your hands away from the working area when
the machine is in operation.
Before performing setting or maintenance work, switch
the device off and unplug the mains plug.
6. Technical data
Rated input voltage
Nominal power
Motor speed
Output speed
(continuously adjustable)
Chuck adapter
Drill spindle cone
Chuck
Drilling table size
Base plate size
Angle adjustment
Drilling depth
Column diameter
Machine dimensions
L x W x H
230-240V~ 50Hz
750 W / S2 10 min*
1450 rpm
440 - 2580 rpm
B16
MK2
1 - 16 mm
240 x 240 mm
410 x 250 mm
45° - 0° - 45°
80 mm
65 mm
540 x 390 x 950 mm
www.scheppach.com
Weight
Laser class
Laser wavelength
Power of laser
*Operating mode S2, short-term operation
Subject to technical changes!
Noise
The noise levels have been determined in accordance
with EN 62841.
Idle sound pressure level L
Uncertainty K
pA
Idle sound power level L
WA
Uncertainty K
WA
Wear hearing protection.
Excessive noise can result in a loss of hearing.
The specified noise emission values have been measured
in accordance with a standardised test procedure and can
be used to compare one power tool with another.
The specified device emissions values can also be used
for an initial estimation of the load.
Warning:
• The noise emission values can vary from the spec-
ified values during the actual use of the power tool,
depending on the type and the manner in which the
electric tool is used, and in particular the type of work-
piece being processed.
• Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operat-
ing cycle must be taken into account (such as times in
which the power tool is switched off or times in which it is
switched on, but is not running under a load).
38.5 kg
2
650 mm
1 mW
72.1 dB
pA
3 dB
84.2 dB
3 dB
