1 | MI_2218: Modification instruction drain pump for tabletop and floor units
Drain pump 200-240V 50/60 01/23
Activation electronics with housing
01/23
Cable: SC pump f. KD*61-202
Cable W89: Earthing tap
Retaining plate SC-pump 61-202*KD*
01/23
Bracket electronics SC-pump*KD* 01/23
Connection terminal WAGO
221*5pin*4mm
Hexagon head screw M 4x10
Flange nut M4 w. Underhead toothing
Flange nut M6 w. Underhead toothing
Cage nut M6
Cable tie 145 mm/3.4
1
3
1 Drain pump 200-240V 50/60 01/23
2 Activation electronics with housing 01/23
3 Bracket electronics SC-pump*KD* 01/23
4 Retaining plate SC-pump 61-202*KD* 01/23
18 / 208
Component
2
Article number
56.01.949
40.07.630
40.07.755
40.07.975
56.02.049
56.01.849
40.07.972
1004.0666
10.00.916
10.00.709
1106.0802
4005.0101
2
4
