Index 1A01 COM TxPDO-Map Ext. Inputs Ch.1
Index Name
(hex)
1A01:0 COM TxPDO-Map Ext.
Inputs Ch.1
1A01:01 SubIndex 001
1A01:02 SubIndex 002
1A01:03 SubIndex 003
EJ6002
Bedeutung
PDO Mapping TxPDO 2
1. PDO Mapping entry (object 0x6001 (COM Ext. Inputs
Ch.1), entry 0x01 (Rx))
2. PDO Mapping entry (object 0x6001 (COM Ext. Inputs
Ch.1), entry 0x02 (CTS))
3. PDO Mapping entry (14 bits align)
Version: 1.6.0
Inbetriebnahme
Datentyp Flags Default
UINT8 RO 0x03 (3
dez
UINT32 RO 0x6001:01, 1
UINT32 RO 0x6001:02, 1
UINT32 RO 0x0000:00, 14
)
