Index 1601 COM RxPDO-Map Ext. Outputs Ch.1
Index Name
(hex)
1601:0 COM RxPDO-Map Ext.
Outputs Ch.1
1601:01 SubIndex 001
1601:02 SubIndex 002
1601:03 SubIndex 003
EJ6002
Bedeutung
PDO Mapping RxPDO 2
1. PDO Mapping entry (object 0x7001 (COM Ext.
Outputs Ch.1), entry 0x01 (Tx))
2. PDO Mapping entry (object 0x7001 (COM Ext.
Outputs Ch.1), entry 0x02 (RTS))
3. PDO Mapping entry (14 bits align)
Version: 1.6.0
Inbetriebnahme
Datentyp Flags Default
UINT8 RO 0x03 (03
UINT32 RO 0x7001:01, 1
UINT32 RO 0x7001:02, 1
UINT32 RO 0x0000:00, 14
)
