Start-up
Safety
Operating the equipment incorrectly can cause serious injury and damage.
Do not use the functions described until you have thoroughly read and unders-
tood the following documents:
▶
▶
Utilisation in ac-
The TIG robot welding torch is to be used solely for TIG welding and TIG brazing.
cordance with
Utilisation for any other purpose, or in any other manner, shall be deemed to be
„intended pur-
„not in accordance with the intended purpose". The manufacturer shall not be li-
pose"
able for any damage resulting from such improper use.
Utilisation in accordance with the "intended purpose" also comprises
-
-
Commissioning
1
2
An incorrectly adjusted tungsten electrode can damage the gas nozzle.
▶
3
Welding torch connections
WARNING!
these operating instructions
all the operating instructions for the system components, especially the
safety rules
following all the instructions given in this manual
performing all stipulated inspection and servicing work.
Fit plasma torch to robot
Check torch for completeness and correct fitting
CAUTION!
Adjust the tungsten electrode according to the gas nozzle used and the app-
lication.
Check the tungsten electrode setting
(4)
(1)
Connect the hosepack
4
(1) Shielding gas/current
(2) Water return
(2)
(3) Water flow
(4) Cable for collision box
When starting for the first time,
5
make sure the gas flow is correct
Position welding torch (adjust ro-
6
bot)
Purge shielding gas for at least 30
7
seconds
The torch is now ready to use
8
(3)
25
