Scope of supply
and options
Scope of supply Robacta TTW 4500
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
The following options are available with the Robacta TTW 4500 robot welding
torch:
* extension of welding torch holder on robot
Not illustrated:
-
-
-
-
-
-
-
(7)
(8)
(9)
(6)
Hosepack 6 m (19.7 ft.) / 8 m (26 ft.), Fronius F++ connection
Torch cap TTW 4500
Clamping sleeve D = 3.2 mm (1/8 in.)
Tungsten electrode WL 20 D = 3.2 mm (1/8 in.)
Torch holder
Torch body
Stop ring
Gas lens
Shielding gas nozzle
Cold wire feeder with drive (push-pull system): Robacta Plasma KD Drive
Cold wire feeder (push system): Robacta Plasma KD
Hot wire option
Gas lens for 3/4" gas nozzles option
Ignition aid option
Clamping sleeve 1.6 / 2.4 / 4.0 / 4.8 mm (1/16, 3/32, 5/32, 3/16)
Adapter for Fronius Z central connector
(3)
(4)
(5)
*
(1)
(2)
19
