14
English
Wearing the motor unit
The motor unit can be worn in multiple ways:
1 Use the provided clip to attach it to your clothes. The clip is pre-attached to
the motor unit. Slide the clip over your clothes to fasten it tightly (Fig. 15).
2 Wear the provided carrying cord around your body (Fig. 16). Attach the
carrying cord to the clip. Wear the carrying cord cross-body. Make sure that
the carrying cord and the silicone tubes do not get entangled. You can
adjust the length of the carrying cord.
Motor unit part description
1
7 8
LED display description
2 4 6
3 5
10
9
1 Battery indicator
1
2 Timer (minutes)
2
3 Expression icon
4 Stimulation icon
3
4
1 USB power inlet
2 On/off button with pause function
3 Mode selection button
4 'Level down' button
5 'Level up' button
6 LED display
7 Clip (detachable)
8 Loop
9 Tubing port for single breast pump
10 Tubing ports for double breast pump
lights
and vacuum level
indication
