Disassembly of joint brush followed by
assembly of the surface brush
Dismantle the joint brush according
to handling and function described
above.
Open the locking device (K)
15 1
drive arm (P) and, with the lock
applied, (K) put the drive arm (P) with
safety guard (O), onto the drive side of
the motor/gear unit (L), as illustrated.
Release the spring-loaded lock (K),
the drive arm is locked when the
locking device independently returns
to its original position
NOTE!
If the drive unit (P) cannot be pushed
15 1
onto the drive shaft, reach under the
safety guard (O) and turn the hexagonal
drive until the drive unit (P) slides onto
the drive shaft easily and without force.
1
Put the surface brush onto the hexa-
16
gonal drive and then the guide arm
(M), as illustrated, on the steering side
of the motor/gear unit (L).
Now slide the lock (K) into open posi-
17
tion , hold this and press the guide
arm (M) further onto the coupling
shaft up to the stop. Release the
spring-loaded locking device (K). The
guide arm (M) is locked when the
locking device independently returns
to its original position
NOTE!
Whilst assembling the surface brush,
18
make sure that the side part of the
safety guard on guide arm (M) is firm-
ly connected to the safety guard and
is correctly sealed.
6.1.3 Using the surface brush on
rough surface structures e.g. tiles,
paving slabs, exposed aggregate
concrete, stoneware etc.
of the
Figure 19
Place the switched-on device parallel on
19
the surface to be treated. Hold the device
at working angle and make sure that the
rubber lip on the safety guard is just
above the ground. Walk at an even stea-
dy pace and push the device in front of
you. Depending on the degree of soiling,
.
apply light to medium pressure on the
surface brush, adapt your pace of work
to the degree of soiling.
Always work parallel and hold the
device away from your body.
When working close to edges, the
narrower side of the device should
point towards the wall.
In cases of stubborn dirt
you can move the device backwards
and forwards on the spot (like a
scrubber), until the required result
is achieved.
Wet cleaning is also possible in cases
of heavy soiling. Use a sprayer to wet
the surface to be cleaned with water
or a cleaning agent, a GLORIA sprayer
is ideal for this purpose. After wet
cleaning rinse the surface with water.
.
Never lift the device off the ground
whilst switched on during work as
there is danger of entanglement!
27
2
NOTE!
CAUTION! RISK OF INJURY FROM
RUNNING BRUSHING TOOL!
