5

Assembly

Figures 1 - 5
NOTE!
Your device is supplied with the
1
surface brush pre-assembled.
Loose parts supplied must be assem-
bled accordingly when working with
the joint brush.
After removing from the packaging,
loosen screw connection (G)
Next, turn handle (A) as shown in figu-
re and adjust the length of the
3
telescopic tube (F) according to your
body height, as illustrated. 5 locking
positions are available.
In the selected position, turn handle
4
(A) a further 45° and tighten the
height of the telescopic tube (F) with
the screw connection (G) by hand.
As the device should always be gui-
ded and operated with two hands,
adjust the height of the additional
handle (E) as shown in figure
screw tight.
6

Commissioning

WARNING! BEFORE USE
OBSERVE CHAPTER 2 "FOR
YOUR SAFETY".
ATTENTION! Improper use
of the device poses a risk
of damage to property! You
should therefore observe
the following safety instruc-
tions:
Clean the roller/joint brush (N/J)
before each cleaning operation.
The air inlet openings on the
motor/gear unit (L) must not be
blocked or covered.
Check on a small, if possible hid-
den area, that the ground to be
cleaned will not be damaged by
the brushing action.
Never use the device too long on one
spot, always guide at walking pace.

6.1 Operation

.
2
Figures 6 - 9
Slide the loop of the extension cable
6
into the designated cable strain relief
(B) in the handle (A) and fix it in the
designated clip.
NOTE!
The performance of the equipment
may decrease if unnecessarily long
extension cables (>25 m) are used.
If cable reels are used, unroll the enti-
re cable.
The cross-section of the cable used
must be 1.5 mm
and
5
Always place the device parallel on the
7
ground which is to be cleaned. Identify
the most comfortable but also most
effective working angle for yourself and
then adjust the 5 click-stop safety
guard (O) so that the rubber lip is just
above the ground.
Make sure that the surface to
be cleaned is free from debris e.g. sto-
nes, screws etc., which could be flung
up.
Use an extension cable to connect
8
the device to a power outlet (230 V
AC).
