RZ_MULTIBRUSH_Text_GB 27.05.15 16:07 Seite 24

3.2 Elements of the device

A Ergonomic handle
B Cable strain relief
C Power cord
D ON/OFF safety switch
E Additional handle
F Telescopic tube
G Screw connection telescopic tube
H Safety guard for joint brush
I Guiding wheel
J Joint brush unit
K Locking device (2 x left/right)
L Motor/gear unit
M Guide arm (removable)
N Surface brush
O Adjustable safety guard
P Drive arm (removable)
Q Lock button
4

Technical data

MultiBrush
Voltage:
Output:
Rotational speed of joint brush:
Rotational speed of surface brush:
Dimensions
Width:
Height (min):
Height (max):
Weight of joint brush:
Weight of surface brush:
Hand-Arm vibration value:
Sound pressure level L PA :
Sound power level L WA :
Protection class:
Q
P O N M
230 VAC ~ / 50/60 Hz
500 Watt
1600 rpm
1300 rpm
Surface brush 24.0 cm // Joint brush 28 cm
Surface brush 1.15 m // Joint brush 1.04 m
Surface brush 1.35 m // Joint brush 1.24 m
2.9 kg
3.6 kg
< 3.1 m/s 2 (+/- 1.5 m/s 2 )
77 dB
90 dB
II
24
A
B
C
D
E
F
G
H
I
J
K
L
