chute
22
Engine mounting
23 Loading hopper
24 Belt
28 Chain
PLEASE NOTE! Before starting the machine, fill the oil and fuel tanks according to
the operating instructions.
Adding engine oil to the crankcase.
Place the machine on a flat surface and unscrew the oil tank cap. Refill the engine
oil up to the top level on the dipstick.
Refueling
The machine is driven by a four-stroke engine powered by unleaded petrol.
Unscrew the fuel tank cap and pour the petrol (use a funnel), taking care not to
spill the liquid or exceed the maximum petrol level. The tank should be filled to a
level not blocking the fuel filter visibility.
3.3.
PLEASE NOTE! Before starting the machine, pour motor oil and fuel. The The machine
is delivered without engine oil or fuel.
Starting and stopping
1. Place the product on a flat, dry surface, stop the front wheels with the brake and
make sure that the machine cannot be moved.
2. Ensure that the fuel supply valve is in the "ON" position.
3. Move the choke control handle to the "CHOKE" position (only with cold engine).
4. Move the throttle control handle to the "FAST" position.
5. Starting: set the ignition switch to the "ON" position. Take hold of the starter
handle and slowly pull until it stops. Wait for the cable to pull in slightly, then
quickly pull the cable to start the engine.
6. Electric start: Turn and hold the key in the starting position until the engine starts.
Then allow the key to return to its idle position.
7. When the engine starts and is running smoothly, move the choke lever to the
"RUN" position.
8. If the chipper was started on a cold engine, warm up the engine by setting the
throttle lever to half position and increase the speed after about 3-4 minutes.
Device use
EN
component
Loading hopper rubber
59
component
60 Bearing
61 Flange
62 Bearing cup
