1
Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer
We hope your new product brings you much enjoyment
and success.
Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2
Product description (Fig. 1-15)
1.
Operating handle
1a.
On/off switch
1b.
Switch lock
1c.
Throttle
2.
Guide bar
2a.
Guide handle
3.
Lifting eye
4.
Tubular shaft
5.
Battery mount
5a.
Button (charge status indicator)
5b.
Charge status indicator
6.
Battery*
6a.
Release button (battery)
7.
Locking pin
8.
Wing nut
9.
Guide bar mounting
9a.
Locking screw
9b.
Rubber ring
9c.
Retaining clip
9d.
Allen screw
10.
Front tubular shaft
10a.
Protective cap
10b.
Flange
10c.
Receptacle spindle
22 | GB
11.
Protective cover
11a.
Top protective cover
11b.
Allen screw
11c.
Thread cutter
12.
Coil capsule
13.
Cutting blade
13a.
Transport protection
13b.
Spring washer
13c.
Cover
13d.
M10 nut
14.
Carrying strap
14a.
Carabiner hook
14b.
Safety tab
15.
Allen key, 4 mm
16.
Installation spanner
(AF19/21 mm with slotted screwdriver)
17.
Cover
17a.
Unlocking
17b.
Pressure spring
18.
Thread coil
18a.
Trigger
18b.
Notch
18c.
Notches (centre of thread coil)
19.
Thread outlet eyelets
* = may not be included in the scope of delivery!
3
Scope of delivery (Fig. 1-15)
Item QuantityDesignation
2.
1 x
4.
1 x
9.
1 x
9b.
1 x
9c.
1 x
9d.
4 x
10.
1 x
11.
1 x
11a.
1 x
11b.
2 x
12.
1 x
13.
1 x
13a.
1 x
14.
1 x
15.
1 x
16.
1 x
1 x
1 x
4
Proper use
Brush cutter:
The brush cutter (using the cutting knife) is suitable for
cutting shrubs, strong weed and undergrowth.
Grass trimmer:
The grass trimmer (using thread coil with trimming line) is
suitable for cutting lawns, grass areas and light weed.
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
www.scheppach.com
Guide bar
Tubular shaft
Guide bar mounting
Rubber ring
Retaining clip
Allen screw
Front tubular shaft
Protective cover
Top protective cover
Allen screw
Coil capsule
Cutting blade
Transport protection
Carrying strap
Allen key, 5 mm
Installation spanner (AF 19/21 mm with
slotted screwdriver)
Cordless brush cutter
Operating manual
