2.PRODUCT INTRODUCTION
2.1. Overview of the product
2.2. Accessories
Tray
Collects residues that drip when cooking food
on the grills.
Lateral wire grids
Located on both sides of the oven cavity, holds
metal grills and drip pans.
1. Control panel
2. Lateral wire grids
3. Metal grids
4. Tray
5. Oven door
6. Serial number & QR Code
Write here your serial number for future reference
Metal grid
Holds baking trays and plates .
*Push into the oven as indicated by the arrow.
Notch (a) should face downwards and it is the
resting position to prevent the inadvertent
withdrawal.
Soft close
Hinges which ensure an automatic soft and
smooth movement during the closing phase
of the oven door.
EN 15
