ASSEMBLY
1
Hardware Qty
Z01 Flat Washer (M12) 2
Z02 Bolt (M12x25L) 2
Z01
Z02
2
Hardware Qty
Z03 Bolt (M10x20L) 2
Z12 Bolt (M10x60L) 2
Z09 Flat Washer (M10) 4
Z10 Spring Washer (M10) 4
Z03 Z12 Z10 Z09
ENGLISH
3
4
Hardware Qty
Z03 Bolt (M10x20L) 4
Z09 Flat Washer (M10) 6
Z10 Spring Washer (M10) 4
Z13 Bolt (M10x125L) 1
Z14 Nut (M10) 1
Z09
Z13
7
Z14
Z09
Z10
Z03
