7. 4. 6 ASSEMBLY
1
Slide the drip tray into place..
2
Lubricate the tap piston, the hexagonal joint and
the mixer at the points indicated in (see picture 17 -
page 6)2, using only the grease that came with the
machine or other grease for use with food.
3
Reassemble the tap on the container in reverse
order compared to that shown in (see picture 12 -
page 5).
4
Replace the container gasket.
N.B. the rim with the greater diameter must be
rested on the rear wall (see picture 18 - page 6).
5
Reassemble the hexagonal joint and then the
mixer (see picture 19 - page 7).
6
Replace the container by pushing it towards the
back wall, making sure it fits properly onto the
gasket. The locking lever will be lowered until it rests
on the drip tray surface (see picture 20 - page 7).
7
Rinse using a cool beverage in order to
eliminate any remaining sanitising solution from the
bottom of the containers. Dry the inside of the
containers with a disposable paper towel.
7. 5 IN-PLACE SANITIZATION
Sanitising the assembled device, prior to putting into
service, should only be performed, if necessary, as
an additional precaution to the sanitisation of the
disassembled devices described previously, never
instead of it.
1
Prepare a solution of hot water (45-60°C) and
sodium hypochlorite (bleach) at a ratio of 200 ppm
per 2 litres of water.
2
Pour the solution into the containers.
3
Using a suitable brush, wipe the solution onto all
parts above the level of the solution and on the
underside of the lid.
4
Install the lid and operate the dispenser in order
to allow the solution to be stirred for about 2
minutes. Drain the sanitising solution from the
containers through the taps and then dispose of it.
5
Rinse using a cool beverage in order to
eliminate any remaining sanitising solution from the
bottom of the containers. Do not perform further
rinsing.
NOTE: Sanitizing frequency must comply to federal,
state, or local agency having jurisdiction.
8 ROUTINE MAINTENANCE
1
Every day: inspect the dispenser and check for
leaks of product from the gaskets. If you notice
leaks, first make sure that the components of the
dispenser are properly installed, then check that the
gaskets do not require lubrication and finally that
they are not worn or damaged. If they are, replace
t h e m w i t h o r i g i n a l s p a r e p a r t s f r o m t h e
manufacturer.
2
Every month: check that the hexagonal joint
gasket is not worn. If it is, replace the joint itself with
an original spare part from the manufacturer (see
picture 21 - page 7).
22
3
Every month: remove the dust from the
condenser filter on the back of the machine (see
picture 22 - page 7).
ATTENTION
Beware of the condenser fins as they are
sharp.
4
In case of noise it needs to unplug the cooler
and call for service.
5
In case of failure unplug the machine, because
unexpected start again would be possible.
6
It needs to fix everything back in the initial
position after any repairmen, like screws and
covers.
8. 1 MAINTENANCE (TO BE CARRIED
OUT BY QUALIFIED SERVICE
PERSONNEL ONLY)
IMPORTANT
In order to prevent damage to the dispenser,
the plastic parts must only be lubricated with
the grease supplied by the manufacturer or
with another type of grease compatible with
plastic parts.
1
Annually: Remove all the panels and clean the
inside of the machine including the base and the
inside of the panels.
Never remove the anti-condensation material
wrapped around the evaporator outlet tube (the
copper tube located to the right of the geared motor).
If said material is missing or lost, replace with original
spare parts from the manufacturer.
2
Remove any traces of product from the inside of
the evaporator by removing the tray as shown (see
picture 23 - page 7).
