6
Using the controls
DESCRIPTION OF CONTROLS).
7
The dispenser
interruption: the cooling system for each container
will automatically stop when the product is ready to
be dispensed, maintaining the set density. The
mixing devices will still continue to operate.
8
If you use the dispenser with milk-based
products, never switch it off. When not in use
activate the storage function.
7. 1 DESCRIPTION OF CONTROLS
The dispenser is equipped with an ON/OFF switch, a
keypad and a product temperature display. It is
possible to select the dispenser operating mode
using the keypad. The following operating modes are
available:
ICE CREAM OR GRANITA PRODUCTION: in this
mode, the dispenser prepares ice cream or
GRANITA depending on the product in the container.
PRODUCT STORAGE: in this mode, the dispenser
keeps the liquid product at a temperature suitable for
storage. This is useful at night to maintain the quality
of the product and limit the consumption of electricity.
WASHING: in this mode, the mixer rotates at a high
speed and cooling is not enabled. This function is
useful while washing and sanitising the machine to
prevent the sanitising solution from being cooled.
ON/OFF SWITCH
The ON/OFF switch is located under the dispenser
itself, on the left-hand side. Its function is as follows:
Position 0 : the dispenser is off.
Position I : t h e d i s p e n s e r i s e n a b l e d f o r
operation but is in standby mode.
Only the B LED is on.
CONTROL KEYPAD
(see picture 1 - page 4)
The functions of the keys on the keypad are as
follows:
Key A If pressed for 2 seconds, this allows the
user to switch from standby mode to
operating mode and vice versa. In ope-
rating mode, the mixer rotates and coo-
ling is enabled.
If pressed briefly while the machine is
running, it allows users to turn the
dispenser lights, if any, on and off.
Key B LED operation
Key C If pressed in ICE CREAM OR GRA-
NITA PRODUCTION mode, this increa-
ses the density of the product.
Key D If pressed in ICE CREAM OR GRA-
NITA PRODUCTION mode, this decre-
ases the density of the product.
18
(see Chapter
must operate without
7.1
Key E If pressed, this activates the STORAGE
function. This operating mode is confir-
med when LED F lights up, either fla-
shing or continuously.
Key H If pressed, this activates the ICE
CREAM OR GRANITA PRODUCTION
function. This operating mode is confir-
med when LED G lights up, either fla-
shing or continuously.
Sensor I Cup presence sensor: detects when a
cup or cone is placed under the dispen-
sing tap and enables the speed of the
mixer to be increased so that the pro-
duct is dispensed more easily.
The following symbols are present on the display:
(see picture 2 - page 4)
J When this symbol is on, the compressor is
operating.
K when this symbol is on, the cooling solenoid
valve is open.
L when this symbol is on together with the M
symbol, the machine is in SuperService mode.
M when this symbol is on, the machine is in
Service mode.
N when this symbol is on and the display shows
the indication "COU", the lid is not present and
the machine cannot be operated.
O when this symbol is on, a temperature alarm
has occurred during operation.
P Temperature of product.
Q Indication of the density set.
R temperature scale set (°C or °F).
S when this symbol is on, the presence of a cup
or cone under the dispensing tap has been
detected.
T when this symbol is on, the keyboard is locked.
U when this symbol is on, an alarm is in progress.
V when this symbol is on, the timer is enabled.
FOR DISPENSER OPERATION
Set the ON/OFF switch to I. The red LED B will be on.
Hold down key A until the dispenser starts up.
Use keys E or H to select the desired dispenser
operating mode:
Key E If you just want to store the product.
Key H If you want to prepare ICE CREAM OR
GRANITA
In machines with several tanks, pressing the key
relating to the activated operating mode will then
make it possible to switch off both mixing and
