Safety input and command status (TEST mode)
With no currently active commands, press the TEST button and check the following:
DISPLAY
The release handle is open.
(Sb)
The safety STOP contact is open.
Sensing edge COS1 not connected or
incorrectly connected.
Sensing edge COS2 not connected or
incorrectly connected.
Photocell FT1 not connected or
incorrectly connected.
Photocell FT2 not connected or
incorrectly connected.
Both limit switches in open contact
state or not connected.
Gate is at gate closed limit switch.
Gate open limit switch absent or not
connected.
Gate is at gate closed limit switch.
Gate closed limit switch absent or
not connected.
If occurs with no voluntary command,
the contact (N.O.) may be faulty or
one of the buttons may be incorrectly
connected.
If occurs with no voluntary command,
the contact (N.O.) may be faulty or
the timer may be incorrectly con-
nected.
N.B: press TEST to exit TEST mode.
We recommend troubleshooting safety device and input status errors with "corrective action by software" only.
72
POSSIBLE CAUSE ACTION BY SOFTWARE
-
-
Set the parameter if
not used or to disable.
Set the parameter if
not used or to disable.
Set the parameter
e if not used or to
disable.
Set the parameter
e if not used or to
disable.
-
If the limit switch state
indicated is incorrect, check
the setting of parameter .
-
If the limit switch state
indicated is incorrect, check
the setting of parameter .
-
-
-
-
-
-
PHYSICAL CORRECTIVE ACTION
Close the release handle and turn the
key to the close position.
Check that the release contact is
connected correctly.
Install a STOP button (NC) or jumper the
ST contact with the COM contact.
Jumper contact COS1 with contact
COM, if not used or to disable.
Jumper contact COS2 with contact
COM, if not used or to disable.
Jumper contact FT1 with contact COM,
if not used or to disable. Check
connection referring to relative
connection diagram.
Jumper contact FT2 with contact COM,
if not used or to disable. Check
connection referring to relative
connection diagram.
Check connection of limit switches.
-
Check connection of limit switches.
-
Check connection of limit switches.
Check PP - COM contacts and
connections to buttons.
Check CH - COM contacts and
connections to buttons.
Check AP - COM contacts and
connections to buttons.
Check PED - COM contacts and
connections to buttons.
Check ORO - COM contacts. Contact
must not be jumpered if not used.
