KPS DCM300MINI Benutzerhandbuch Seite 9

DCM300MINI
3.2.2 DC Voltage
Measuring range
400mV
4V
40V
400V
600V
Overload protection: AC/DC 600V
Maximum input voltage: 600V AC (RMS) or 600V DC
Note:
In the small voltage measuring range, the probe is not
connected with the circuit to be tested, and the meter may
have fluctuating readings, which is normal and
caused by the meter's high sensitivity. This does not affect
actual measurement results.
3.2.3 AC Voltage
Measuring range
[1]
400mV
4V
40V
400V
600V
[1]
LCD displays 0 counts when the reading < 30 counts.
Input impedance: 10ΜΩ
Overload protection: AC/DC 600V
Frequency response: 45 to 500Hz
When applying 3V/m Radiated EM field on the product, the
product will be loss/error of function around the frequency
range of 80MHz to 140MHz. The product work normally
after removing the radiated signal.
Note:
In the small voltage measuring range, the probe is not
connected with the circuit to be tested, and the meter may
have fluctuating readings, which is normal and caused
by the meter's high sensitivity. This does not affect actual
measurement results.
Resolution
0.1mV
0.001V
0.01V
0.1V
1V
Resolution
0.1mV
0.001V
0.01V
0.1V
1V
8
EN
Accuracy
±(0.5% reading +
6 digits )
±(0.5% reading +
3 digits )
Accuracy
±(1.0% reading +
5 digits)
±(1.0% reading +
3 digits )
