KPS DCM300MINI Benutzerhandbuch Seite 4

DCM300MINI
1.3 Mark
Note Important safety information, refer to the
instruction manual.
Application around and removal from
UNINSULATED HAZARDOUS LIVE conductors
is permitted.
Caution, possibility of electric shock Equipment
protected throughout by double insulation or
reinforced insulation.
Conforms to UL STD 61010-1, 61010-2-032;
Certified to CSA STD C22.2 61010-1-12,
61010-2-032
Complies with European (EU) safety standards
Earth (ground) TERMINAL
Direct current
Alternating current
Do not discard this product or throw away.
CAT III: MEASUREMENT CATEGORY III is applicable to
test and measuring circuits connected to the distribution
part of the building's low-voltage MAINS installation.
1.4 Maintenance
1.4.1 Don't try to open the meter bottom case to adjust
or repair. Such operations can only be performed by
technicians who fully understand the meter and electrical
shock hazard.
1.4.2 Before opening the meter bottom case or battery
cover, remove probe from the circuit to be measured.
1.4.3 To avoid wrong readings causing electric shock,
when appears on the meter display, replace the
battery immediately.
1.4.4 Clean the meter with damp cloth and mild detergent.
Do not use abrasives or solvents.
1.4.5 Power off the meter when the meter is not used.
Switch the knob switch to
1.4.6 If the meter is not used for long time, remove the
battery to prevent the meter being damaged.
position.
3
EN
