DCM300MINI
4.5 Measurement Preparation
1) Dial the knob switch to turn on the power. When battery
voltage is low (about 3.6V), LCD displays
Replace the battery.
2) Symbol means that input voltage or current should
not be more than the specified value, which is to protect
the internal circuit from damage.
3) Dial the knob switch to required measuring function and
range.
4) When connecting the test leads to the DUT(Device
Under Test), connect the common test leads before
connecting charged test leads. When removing the test
leads, remove charged test leads first.
4.6 Current Measurement
Warning
Electric shock hazard.
Remove the probe from the meter before measuring
current.
1) Dial the knob switch to
meter is in AC current measurement state.
2) Hold the trigger, clamp one lead of measurement circuit
to be tested.
3) Read the current value on the LCD.
Note:
1) Clamping two or more leads of circuit to be tested
simultaneously will not get the correct measured results.
2) To avoid position errors, place the tested lead in the
center of clamp.
3) indicates that maximum input AC current is 600A.
4.7 Voltage Measurement
Warning
Electric shock hazard.
Pay special attention to avoid shock when measuring high
voltage.
Don't input voltage more than 600V DC or AC(RMS).
or position, the
11
EN
symbol.
