DCM300MINI
(1) The sensing position of NCV
(2) The central of the clamp
(3) Function switch
(4) Resistance, voltage, continuity input jack
(5) Common/Ground input jack
(6) LCD display
(7) Button
(8) NCV indicator
(9) Trigger
(10) Current clamp: used for current measurement.
2.2 Switch, Button and Input Jack Description
Button: used for reading hold.
Button: used for switching measuring function.
Button: used for switching measuring range.
Position: used for turning off the power.
Jack: tensão, resistência, diodo, conexão do fio
de entrada do circuito.
Jack: voltage, resistance, diode, circuit
connection common wire connecting.
Knob
Used for selecting measuring function.
switch
2.3 LCD Display
5
EN
